Oclaro奧蘭若980nm泵浦激光器 400-600mW 帶光柵DCL96
Features
• Two chips utilizing one carrier, one package and one TEC
• High output power, up to 600mW kink free
• Combined power of >1.0W with variable power ratios
• Combined total laser current up to 2200mA
• Minimal thermal or optical cross talks
• Two independent fibers
• Fiber Bragg grating stabilization for wavelength
locking over the entire operating conditions
• Internal thermoelectric heatpump and monitor photodiode
• Hermetically sealed 14 pin butterfly package
• Telcordia GR-468-CORE compliant
• Field-proven high reliability
• RoHS compliant
Applications
• Low noise EDFAs
• Multi stage applications
• Mid-stage Access (MSA) EDFA
• Dense wavelength division multiplexing (DWDM) EDFAs
• Arrayed EDFA for ADD/DROP ROADM applications
>
